Intelligent Level Controller for Complex Process Applications

The Siemens SITRANS LT500 (7ML60) is a versatile level controller designed to provide centralized control and monitoring for continuous level measurement systems.

Unlike a traditional level transmitter, the LT500 works as a powerful controller platform that connects with external measurement devices, processes level signals, manages alarms, and controls pumps or other equipment according to process requirements.

It is widely used in:

•
  Water and wastewater treatment

•
  Pump stations

•
  Storage tanks

•
  Chemical processing

•
  Mining and bulk material handling

•
  Industrial process systems


Flexible Compatibility with Different Level Technologies

One of the key advantages of SITRANS LT500 is its ability to work with multiple Siemens and third-party measurement technologies.

Compatible measurement inputs include:

•
  SITRANS LR110 / LR120 radar level transmitters

•
  SITRANS Probe LU240 ultrasonic level transmitter

•
  Siemens ultrasonic transducers

•
  Generic 4–20 mA level transmitters


This flexibility allows engineers to select the most suitable sensor technology according to the application, medium, and installation conditions.

Continuous Level, Volume and Flow Monitoring

The SITRANS LT500 is designed for applications where level information needs to be converted into actionable process control data.

Functions include:

•
  Continuous level measurement

•
  Tank volume calculation

•
  Open channel flow monitoring

•
  Pump control

•
  Alarm management

•
  Process monitoring


This makes it suitable for both simple level applications and more complex automation systems.

Advanced Pump Control and Process Management

For water and wastewater applications, pump control is one of the most important functions.

The SITRANS LT500 provides:

•
  Single-point or dual-point measurement

•
  Programmable relay outputs

•
  Pump start/stop control

•
  Alternation and duty cycling

•
  Overflow protection

•
  Alarm handling


With multiple relay options, it can manage complex pumping systems without requiring additional control equipment.

Powerful Diagnostics and Signal Monitoring

Reliable level control requires accurate signal evaluation, especially in applications affected by foam, vapor, obstructions, or changing process conditions.

The LT500 provides advanced diagnostic functions including:

•
  Echo and signal quality monitoring

•
  False echo suppression

•
  Fail-safe configuration

•
  Diagnostic alarms

•
  Data logging

•
  Parameter backup and configuration storage


These features help reduce downtime and simplify troubleshooting during operation.

Flexible Communication and System Integration

The SITRANS LT500 supports integration into modern automation systems through multiple communication options.

Available interfaces include:

•
  HART

•
  Modbus RTU

•
  PROFIBUS DP

•
  PROFIBUS PA

•
  PROFINET


This allows easy connection with PLC systems, SCADA platforms, and industrial control networks.

Multiple Versions for Different Application Requirements

The 7ML60 series offers different configurations based on measurement and control requirements.

Available options include:

HydroRanger Version

Designed mainly for:

•
  Ultrasonic level measurement

•
  Water and wastewater applications

•
  Pump control systems


MultiRanger Version

Suitable for:

•
  More complex level applications

•
  Multiple measurement points

•
  Advanced control requirements


The modular configuration allows users to select the required input type, relay quantity, communication method, and enclosure design.

Typical Applications

Water & Wastewater Treatment

Suitable for:

•
  Pump stations

•
  Lift stations

•
  Clarifiers

•
  Storage basins

•
  Open channel flow measurement


Industrial Storage Tanks

Used for:

•
  Chemical tanks

•
  Process vessels

•
  Utility water systems

•
  Material inventory monitoring


Mining & Bulk Material Handling

Applied in:

•
  Slurry level monitoring

•
  Material storage

•
  Process water management


FAQ

What is Siemens 7ML60?

Siemens 7ML60 is the order series for the SITRANS LT500 continuous level controller, used for level, volume, volume flow, and pump control applications with ultrasonic, radar, or 4–20 mA level devices.

Is SITRANS LT500 a level transmitter?

No. The SITRANS LT500 is a level controller, not a standalone level sensor. It receives signals from compatible level transmitters or sensors and performs monitoring, calculation, alarm, and control functions.

What sensors can be connected to SITRANS LT500?

It can connect with:

•
  Siemens SITRANS LR radar transmitters

•
  SITRANS Probe LU240 ultrasonic transmitters

•
  Siemens ultrasonic transducers

•
  Other 4–20 mA level devices


Can SITRANS LT500 control pumps?

Yes. The LT500 includes programmable relay outputs and dedicated pump control functions, making it suitable for pump stations and wastewater applications.

What is the difference between SITRANS LT500 HydroRanger and MultiRanger?

•
  HydroRanger: Mainly designed for ultrasonic level applications with simpler measurement requirements.

•
  MultiRanger: Designed for more advanced applications requiring additional measurement points and control functions.


Both belong to the SITRANS LT500 family and share the same controller platform.

Why choose SITRANS LT500 instead of a standard level transmitter?

A standard level transmitter only measures level, while the LT500 adds control intelligence, including pump management, alarms, volume calculation, diagnostics, and communication functions. It is especially valuable in automated water and industrial process systems.
