Reliable Chlorine Dioxide Monitoring for Disinfection Control
The Memosens CCS50E is designed for applications where chlorine dioxide concentration needs to be monitored continuously to maintain effective disinfection.
By providing stable measurement values directly in the process, it helps operators maintain the required disinfectant level while avoiding unnecessary chlorine dioxide overdosing.
Digital Memosens Technology for Easier Maintenance
The CCS50E uses Memosens 2.0 technology, which stores calibration data and sensor information digitally inside the sensor.
This allows pre-calibration outside the process and enables faster sensor replacement with reduced commissioning effort.
Amperometric Measurement for Stable ClO₂ Detection
The sensor uses a closed, membrane-covered amperometric measuring cell to determine dissolved chlorine dioxide.
The two-electrode system provides reliable measurement performance for continuous disinfection monitoring applications.
Designed for Water Treatment and Utility Applications
The CCS50E is suitable for a wide range of applications where chlorine dioxide is used as a disinfectant.
Typical applications include:
Drinking water disinfection
Cooling tower water monitoring
Process water treatment
Beverage production water systems
Reverse osmosis systems
Fast Response and Low Maintenance Operation
The sensor provides fast response to process changes and supports reliable monitoring with low maintenance requirements.
Combined with compatible Liquiline transmitters, it can be integrated into complete liquid analysis systems.
Key Features
Digital chlorine dioxide sensor
Memosens 2.0 technology
Amperometric measurement principle
Measuring ranges:
0–5 mg/l ClO₂
0–20 mg/l ClO₂
0–200 mg/l ClO₂
Process temperature 0–55°C
Maximum process pressure 2 bar abs
Closed membrane-covered measuring cell
PVDF membrane system
Integrated temperature sensor
Fast sensor exchange with pre-calibration capability
Compatible with Liquiline transmitters
Suitable for drinking water and process water applications
Typical Applications
Drinking Water Disinfection
Monitoring chlorine dioxide concentration to ensure effective water disinfection and maintain water quality.
Cooling Water Systems
Helping prevent microbial growth by maintaining suitable disinfectant levels in cooling systems.
Food and Beverage Processing
Monitoring process water used for hygienic production, cleaning and product-related applications.
Reverse Osmosis Systems
Checking residual chlorine dioxide levels and ensuring disinfectant removal where required.
Frequently Asked Questions
What is the Endress+Hauser Memosens CCS50E used for?
The CCS50E is a digital sensor for measuring dissolved chlorine dioxide in water and process applications.
Is CCS50E a chlorine sensor?
No. The CCS50E is specifically designed for chlorine dioxide (ClO₂) measurement. Endress+Hauser has separate sensors for free chlorine measurement.
What measurement principle does CCS50E use?
The CCS50E uses an amperometric measurement principle with a membrane-covered measuring cell.
What is the measuring range of CCS50E?
The sensor is available with three measuring ranges:
0–5 mg/l ClO₂
0–20 mg/l ClO₂
0–200 mg/l ClO₂
depending on the selected version.
What is the maximum process temperature?
The CCS50E supports process temperatures from 0 to 55°C (non-freezing).
Which transmitter is used with CCS50E?
The CCS50E is designed for connection with compatible Endress+Hauser Liquiline transmitters using Memosens digital technology.
What are the advantages of Memosens technology?
Memosens stores calibration and sensor data digitally, allowing easier sensor replacement, better data integrity and simplified maintenance.
