Reliable Turbidity Measurement for Water Applications

Water quality monitoring requires accurate and stable turbidity measurement, especially in drinking water production and industrial water treatment.

The CUS52D is designed for drinking water, process water, saline water and industrial utility applications, providing reliable measurement from raw water intake through water treatment and distribution processes.

Laboratory-Level Accuracy in Process Measurement

The sensor uses a nephelometric measurement principle with 90° scattered light according to ISO 7027, allowing accurate turbidity monitoring directly in the process.

This helps reduce the gap between laboratory analysis and online process measurement.

Flexible Installation for Different Processes

The CUS52D supports multiple installation options, including:

•
  Inline installation

•
  Flow cell installation

•
  Retractable assemblies

•
  Immersion measurement


The hygienic stainless steel version can also be mounted directly into pipelines with clamp connections, making it suitable for drinking water applications.

Smart Sensor with Memosens Technology

With Memosens digital technology, the CUS52D stores sensor data and calibration information, helping simplify commissioning, maintenance and predictive sensor management.

Designed for Long-Term Operation

The sensor design focuses on stable measurement performance and reduced maintenance requirements.

Its robust construction, sapphire optical windows and IP68 protection make it suitable for continuous operation in demanding water applications.

Key Features

•
  Digital turbidity sensor

•
  Designed for drinking water and process water applications

•
  Measuring range: 0.000 to 4000 FNU

•
  Measuring principle: 90° scattered light according to ISO 7027

•
  Memosens digital communication

•
  Laboratory-level turbidity measurement accuracy

•
  Inline and immersion installation options

•
  Hygienic stainless steel version available

•
  Stainless steel version material: 1.4404

•
  Optical windows: Sapphire

•
  Protection rating: IP68

•
  Stainless steel version process temperature: -20 to 85°C

•
  Plastic version process temperature: -20 to 60°C

•
  Stainless steel version pressure range: 0.5 to 10 bar abs

•
  Plastic version pressure range: 0.5 to 6 bar abs


Typical Applications

Drinking Water Treatment

Used for turbidity monitoring in:

•
  Raw water intake

•
  Water treatment processes

•
  Filtration monitoring

•
  Distribution networks


Process Water

Suitable for industrial water quality monitoring where stable turbidity measurement is required.

Utility Systems

Used in industrial utilities for continuous monitoring of water quality parameters.

Saline Water Applications

The plastic version is suitable for applications involving saline media, including desalination processes.

FAQ

What is the Endress+Hauser CUS52D?

The CUS52D is a digital turbidity sensor designed for drinking water, process water and utility applications.

What does the CUS52D measure?

The CUS52D measures turbidity using a scattered light measurement principle according to ISO 7027.

What is the measuring range of CUS52D?

The measuring range is 0.000 to 4000 FNU.

Does CUS52D support Memosens?

Yes. The CUS52D uses Memosens digital technology for data integrity and easier sensor management.

Can CUS52D be installed directly in pipelines?

Yes. The hygienic stainless steel version can be installed directly into pipelines with clamp connections, helping avoid additional bypass installations.

Which industries use CUS52D?

Typical applications include drinking water production, process water treatment, saline water applications and industrial utilities.
