Short Introduction
Many customers start with the same question:
“Can you recommend a model?”
But in reality—
the model is almost irrelevant. The application is everything.
The same level transmitter:
- Can run reliably for 10 years in one plant
- But fail within months in another
The difference is not the product, but: whether it matches the application
This guide won’t give you a model list. Instead, it will show you:
The 5 key questions you must answer before selecting a level instrument
1. Can the Medium Be in Contact? (This Decides the Technology Type)
One of the most common mistakes in selection is ignoring this basic question:
Can the instrument directly contact the liquid?
Why does this matter?
Because once there is contact, the sensor must withstand:
- Corrosion
- Temperature
- Long-term exposure to the medium
If your liquid is:
- Strong acid or alkali
- High temperature
- Prone to crystallization or buildup
The result is often:
Diaphragm corrosion
Sensor failure
Increasing measurement errors
How to Judge?
Ask yourself one simple question:
Would you leave a piece of metal immersed in this liquid long-term?
If the answer is “No,” then:
Non-contact measurement should be your priority
Selection Logic
Non-contact (Preferred)
Contact (When conditions allow)
- Differential pressure level transmitter
- Float / capacitive sensors
Summary:
Contact = Risk, Non-contact = Stability
2. Do You Need Continuous Measurement or Just a Switch Signal?
Many people focus on accuracy first—but that’s not the right question.
The real question is:
What kind of information do you actually need?
Continuous Measurement (Transmitters)
Used for:
- Tank inventory
- Process control
- Monitoring systems
Features:
- Real-time level output (e.g., 4–20 mA)
- Trend monitoring
Point Level Measurement (Level Switch)
Used for:
- Overflow protection
- Dry-run prevention
- Alarm systems
Features:
- Only “Yes/No” signal
- No exact level value
Why This Matters
If you only need an alarm but choose a transmitter:
Higher cost + unnecessary complexity
If you need control but choose a switch:
The system cannot operate accurately
Analogy:
Continuous = Fuel gauge
Switch = Low fuel warning light
3. How Complex Is the Environment? (This Affects Accuracy)
Many level measurement problems are not caused by the instrument itself, but by:
Harsh process conditions
You should consider:
- Is there foam?
- Is there vapor?
- Is the surface unstable?
- Is there agitation?
Why It Matters
Most level technologies rely on signal reflection or pressure:
- Ultrasonic → sound reflection
- Radar → electromagnetic waves
- Differential pressure → hydrostatic pressure
If the environment has:
- Foam → signal absorption
- Vapor → signal interference
- Agitation → unstable surface
The result:
Fluctuating readings
Unstable signals
Occasional signal loss
Selection Logic
Simple conditions (clean liquids, no disturbance)
- Ultrasonic (cost-effective)
Complex conditions (steam, foam, agitation)
- Radar (more reliable)
Summary:
The more complex the environment, the higher the technology requirement
4. Is Installation Actually Possible? (A Common Real-World Problem)
This is often overlooked but very practical:
Can the instrument actually be installed?
You need to consider:
- Open tank or closed tank
- Available mounting space
- Flange or thread connections
- Cable routing and maintenance access
Why This Matters
In many real projects:
The instrument is correctly selected, but:
It doesn’t fit physically
It is blocked by structures
It cannot be maintained
Result: redesign or rework.
Typical Examples
Small tank with limited top space
→ Large radar may not fit
Pressurized or closed tank
→ Better suited for:
- Differential pressure
- Process-connected radar
Summary:
Selection is not just “can it measure,” but also “can it be installed”
5. Are You Buying Equipment or Reliability?
This is the most practical question:
What are you really paying for?
Low-Cost Options
- Ultrasonic
- Float
Pros:
- Lower price
- Easy installation
But:
More sensitive to environment
High-Stability Options
- Radar level transmitter
- Servo level gauge
Pros:
- High reliability
- High accuracy
- Low maintenance
Why This Matters
Choosing a cheaper device may lead to:
Frequent maintenance + downtime losses
Summary:
Cheap buys equipment, expensive buys stability
Final Summary: Level Selection in 5 Steps
Contact or non-contact
Continuous measurement or switch
Process conditions complexity
Installation feasibility
Cost vs reliability
These 5 questions determine 90% of your selection decision
